Corpus II for Street (New Info!) > Legrest Actuators
/Legrest Actuators.jpg)
| Pos | Part | D365 Part | Description |
|---|---|---|---|
| 1.1 | 312903-28-0 | INSTALL ASSEMBLY | |
| 2.1 | 312861 | BRACKET | |
| 3.1 | 600205-99-0 | BOLT MC6S 10x 30 fzb * | |
| 4.1 | 600241-99-0 | 600241 | WASH BRB 10.5x20x2 fzb |
| 5.1 | 601231-99-0 | 601231 | BOLT MC6S 10x 55 fzb |
| 6.1 | 600229-99-0 | 600229 | LOCK NUT M10 FZB |
| 7.1 | 302330-99-0 | 302330 | ACTU SLEEVE 30 HD3 ROBO CII PSJR K450 VS |
| 8.1 | 301592-99-0 | 301592 | ACTU SLEEVE, RECL/LEGR CII, HD3, PSJR, ROBO |
| 9.1 | 600277-99-0 | 600277 | BOLT MC6S 10x 45 fzb |
| 10.1 | 612326-00-0 | ACTUATOR LA28C 156+150 O13,2+O13,15 | |
| 11.2 | 1821542 | MANUAL LEGREST KIT | |
| 12.1 | 312853-40-0 | 312853 | TUBE 100 mm |
| 13.1 | 312331 | INNER TUBE | |
| 14.1 | 312330 | OUTER TUBE | |
| 15.1 | 602328-00-0 | 602328 | NON-INDEXING PLUNGER ADJ BOLT, MANUAL LINKAGE |
| 16.1 | 312905-28-0 | INSTALL ASSEMBLY | |
| 17.1 | 312861 | BRACKET | |
| 18.1 | 600205-99-0 | BOLT MC6S 10x 30 fzb * | |
| 19.1 | 600241-99-0 | 600241 | WASH BRB 10.5x20x2 fzb |
| 20.1 | 601231-99-0 | 601231 | BOLT MC6S 10x 55 fzb |
| 21.1 | 600229-99-0 | 600229 | LOCK NUT M10 FZB |
| 22.1 | 1827733 | 602652 | SPACER NYLON 10.5x20x5 HDPE BLACK |
| 23.1 | 1827732 | 602649 | SPACER NYLON 10.5x20x7 HDPE |
| 24.1 | 600277-99-0 | 600277 | BOLT MC6S 10x 45 fzb |
| 25.1 | 316188 | LEGREST POWER KIT R-net | |
| 26.1 | 1824118 | 1824118 | ACTU ICS LEGREST - C4/500 STR CII RE25 156+150 |
| 27.1 | 317714 | BRACKET | |
| 28.1 | 600205-99-0 | BOLT MC6S 10x 30 fzb * | |
| 29.1 | 600241-99-0 | 600241 | WASH BRB 10.5x20x2 fzb |
| 30.1 | 602159 | SCREW DIN 7984 M10x50 Fe/Zn | |
| 31.2 | 1827729 | 313794 | BUSHING, ACTUATOR |
| 32.1 | 600229-99-0 | 600229 | LOCK NUT M10 FZB |
| 33.1 | 600256-99-0 | 600256 | NUT M6M 10 fzb |
